CORE SERIES

NTW-01R

Previous slide
Next slide

This tweeter speaker, with its stainless steel housing and high-quality design, is well-suited for reproducing high-frequency sounds with clarity and precision. It offers a good balance between sensitivity and power handling, making it a versatile component for various audio applications. The specified mounting dimensions and weight make it suitable for various speaker cabinet designs and installations.

Specification
Model
NTW-01R (25 Core Tweeter)
Product Process
Stainless steel housing, hand-polished
Product Design
1.5 Inch / 25 mm Silk Dome with optional acoustic chamber, stainless steel clamping ring with rubber ring, and screw set
Impedance
4 Ω
Frequency Response
1KHz - 20KHz
Sensitivity
≧ 89 db
Rated Power
15 W
Peak Power
30 W
Mounting Diameter
60 mm
Screw Diagonal Diameter
45 mm
Mounting Hole Diameter
46 mm
Mounting Depth
25 mm
Weight
127 gram
