CORE SERIES
NTW-03
This tweeter speaker, with its stainless steel housing and Silver Grey Sand Textured Powder Coating. It is good balance between sensitivity and power handling, can be drive by DSP Amplifier. The specified mounting dimensions and weight make it suitable for various speaker cabinet designs and installations.
| Specification | |
|---|---|
|
Model |
NTW-03 (1.5 Inch Core） |
|
Product Process |
Stainless steel housing, Silver Grey Sand Textured Powder Coating |
|
Product Design |
1.5 Inch / 25 mm Silk Dome with optional acoustic chamber, stainless steel clamping ring with rubber ring, and screw set |
|
Impedance |
4 Ω |
|
Frequency response |
1KHz – 20KHz |
|
Sensitivity |
≧ 89 db |
|
Rated power |
20 W |
|
Peak power |
55 W |
|
Mounting Diameter |
53 mm |
|
Screw Diagonal Diameter |
45 mm |
|
Mounting Hole Diameter |
46 mm |
|
Mounting Depth |
25 mm |
|
Weight |
105 gram |
